The co-rotating parallel twin screw units are used for compounding materials where thorough mixing is important. Co-rotating twin-screw extruders usually have modular configurations, which makes the equipment quite flexible for adapting to changing applications and material properties.
Model | Diameter(mm) | L/D | rpm | Motor Power(kW) | Single screw torque(N·m) | Torque Level(T/A³) | Capacity(Kg/h) |
TSK-35B | 35.6 | 32-68 | 400 | 15 | 175 | 6.48 | 10-55 |
500 | 18.5 | 174 | 6.44 | 10-90 | |||
600 | 22 | 172 | 6.41 | 15-110 | |||
TSK-50B | 50.5 | 32-68 | 400 | 37 | 438.4 | 5.92 | 60-200 |
500 | 45 | 417 | 5.63 | 75-230 | |||
600 | 55 | 433.4 | 5.85 | 80-247 | |||
TSK-65B | 62.4 | 32-68 | 400 | 75 | 862 | 6.13 | 150-375 |
500 | 90 | 832 | 5.92 | 180-450 | |||
600 | 110 | 850 | 6 | 220-550 | |||
TSK-75B | 71 | 32-68 | 400 | 110 | 1312.67 | 6 | 220-550 |
500 | 132 | 1241 | 5.75 | 280-650 | |||
600 | 160 | 1261 | 5.74 | 330-700 | |||
TSK-95B | 91 | 32-68 | 400 | 280 | 3236.4 | 6.82 | 600-1260 |
500 | 315 | 2903 | 6.12 | 700-1400 | |||
600 | 355 | 2797 | 5.89 | 850-1800 |
